| total rotational |
300°±5° |
nominal power |
a:0.1w;b、c:0.33w |
| rotational torque |
2～20mn.m |
max operating volerance |
ac160v |
| rotationa stopper strength |
600mn.m |
terminal power |
r≥250kω 0.1%r
max
250kω＞r＞10kω 20ω
max
10kω≥r 10ω
max |
| push pull strength |
70n |
| operating angle/push and pull
lengthstroke |
50°±10°/3mm |
slide noise |
≤47mv |
| total resistance range |
a:1kω～2mω b、c;4.7kω～470kω |
insulation resistance |
more than 100mω at dc500v |
| total resistance tolerance |
±20%(more than 1mω±30%) |
switch connect resistance |
less than 30mω |
| resistance taper |
a、b、c、z |
switch operating voltage、carrent |
ac250v 1/16a |
| withstand voltage |
ac600v 1 minute |
switch withstand voltage |
ac4000v 1 minute |
| |
|
operation life |
10,000 cycles |
